Tapered Plug and Threaded Tapered Tube plug.
Manufacturer and exporters of Tapered Plug and Threaded Tapered Tube plug.
ASEC are one of the precious manufacturer of High-Pressure Tube Plugs for heat exchangert, supplier of ASTM A105 Heat Exchanger Tube Plugs, exporter of Carbon Steel Tube LTCS A350 LF2 Tube Plug, Nickel Alloy 200/201 Tube Plugs Exporter in Mumbai, India.
We hot deal suppliers of Heat Exchanger Tapered Tube Plugs, Heat Exchanger Tube Plugs Dealer, Monel 400 Boiler Tube Plugs, Carbon Steel A105 Tube Plug Supplier, Copper Nickel 90/10 Condensor Tube Plugs, Heat Exchanger Tapered Tube Plug Manufacturer in India.
Specifications
Dimensions : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799.
Size : 1/4″ NB TO 4″ NB
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Form : Tube Plugs / Tube Plugs
Type : Screwed-Threaded NPT, BSP, BSPT Fittings.
Application Industries
In bridges and other structural steel works
Automobile industry
Agriculture equipment
Pylons and other architectural structures
Offshore industries
Transportation equipment
Spiral Cases and penstocks in power plants
Tube, Tube Plugs Material & Grades :
Stainless Steel Tube Plugs : ASTM A182 F304, F304L, F306, F316L, F304H, F309S,
F309H, F310S, F310H, F316TI, F316H, F316LN, F317, F317L, F321, F321H, F11, F22, F91,
F347, F347H, F904L, ASTM A312/A403 TP304, TP304L, TP316, TP316L.
Carbon Steel Tube Plugs : ASTM/ ASME A 105, ASTM/ ASME A 350 LF 2, ASTM
/ ASME A 53 GR. A & B, ASTM A 106 GR. A, B & C. API 5L GR. B, API 5L X 42, X 46,
X 52, X 60, X 65 & X 70. ASTM / ASME A 691 GR A, B & C.
Alloy Steel Tube Plugs : ASTM / ASME A 182, ASTM / ASME A 335, ASTM / ASME
A 234 GR P 1, P 5, P 9, P 11, P 12, P 22, P 23, P 91, ASTM / ASME A 691 GR 1 CR,
1 1/4 CR, 2 1/4 CR, 5 CR, 9CR, 91.
Copper Nickel Tube Plugs : ASTM / ASME SB 111 UNS NO. C 10100 , C 10200 ,
C 10300 , C 10800 , C 12000, C 12200, C 70600 C 71500, ASTM / ASME SB 466 UNS
NO. C 70600 ( CU -NI- 90/10) , C 71500 ( CU -NI- 70/30).
Duplex & Super Duplex Steel Tube Plugs : ASTM A 182 – F 51, F53, F55 S 31803,
S 32205, S 32550, S 32750, S 32760, S 32950.
Nickel Alloy Tube Plugs : ASTM / ASME SB 564 UNS 2200 (NICKEL 200) , UNS 2201 (NICKEL 201 ) , UNS 4400 (MONEL 400 ) , UNS 8020 ( ALLOY 20 / 20 CB 3 ) , UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600 ) , UNS 6601 (INCONEL 601) , UNS 6625 (INCONEL 625) , UNS 10276 (HASTELLOY C 276)..
| Metal Tapered Plugs – Tube Plug Sizing Chart | ||||
| Tube OD | Gauge | Dimension (Inches) | ||
| “A” Small End | “B” Large End | “L” Length | ||
| 1/4″ | 18-24 | 0.141″ | 0.235″ | 1-1/4″ |
| 3/8″ | 12-24 | |||
| 3/8″ | 15-24 | 0.213″ | 0.371″ | 1-3/4″ |
| 1/2″ | 13-15 | |||
| 1/2″ | 15-24 | 0.337″ | 0.495″ | |
| 5/8″ | 12-14 | |||
| 5/8″ | 14-24 | 0.449″ | 0.625″ | |
| 3/4″ | 10-14 | |||
| 3/4″ | 14-24 | 0.564″ | 0.750″ | |
| 7/8″ | 10-13 | |||
| 1″ | 8-9 | |||
| 7/8″ | 15-24 | 0.706″ | 0.875″ | |
| 1″ | 10-15 | |||
| 1″ | 13-18 | 0.776″ | 0.934″ | |
| 1″ | 18-24 | 0.892″ | 1.050″ | |
| 1-1/8″ | 13-17 | |||
| 1-1/8″ | 15-24 | 0.949″ | 1.125″ | 2″ |
| 1-1/4″ | 10-14 | |||
| 1-1/4″ | 13-19 | 1.010″ | 1.186″ | |
| 1-1/4″ | 19-24 | 1.147″ | 1.323″ | |
| 1-1/2″ | 10-24 | 1.200″ | 1.495″ | 3″ |
| 1-1/2″ | 14-24 | 1.305″ | 1.600″ | |
| 1-3/4″ | 6-13 | |||
| 1-3/4″ | 14-22 | 1.575″ | 1.870″ | |
| 2″ | 6-13 | |||
| 2″ | 12-22 | 1.700″ | 1.995″ | |
| 2-1/4″ | 6-13 | 1.805″ | 2.100″ | |
| 2-1/2″ | 5-18 | 2.000″ | 2.375″ | |
| 2-3/4″ | 4-10 | 2.232″ | 2.500″ | |
| 3″ | 5-12 | 2.524″ | 2.834″ | 4″ |
| 3″ | 10-23 | 2.625″ | 3.000″ | |
| 3-1/4″ | 7-14 | 2.875″ | 3.125″ | |
| 3-1/4″ | 13-23 | 3.010″ | 3.250″ | |
| 3-1/2″ | 7-12 | 3.125″ | 3.375″ | |
| 3-1/2″ | 13-23 | 3.260″ | 3.500″ | |
| 3-3/4″ | 5-12 | 3.274″ | 3.567″ | |
| 3-3/4″ | 13-23 | 3.510″ | 3.750″ | |
| 4″ | 5-12 | 3.524″ | 3.817″ | |
| 4″ | 13-23 | 3.782″ | 4.000″ | |
| Metric OD | Wall Thickness | Imperial OD | Wall Thickness | Nominal Bore mm | WT / Metre |
| 4.76MM | 0.71MM | 3/16″OD | 22G | 3.34 | 0.077 |
| 6.35MM | 1.63MM | 1/4″OD | 16G | 3.09 | 0.206 |
| 6.35MM | 1.22MM | 1/4″OD | 18G | 3.91 | 0.167 |
| 6.35MM | 0.91MM | 1/4″OD | 20G | 4.53 | 0.133 |
| 7.94MM | 0.91MM | 5/16″OD | 20G | 6.11 | 0.172 |
| 9.52MM | 1.63MM | 3/8″OD | 16G | 6.26 | 0.345 |
| 9.52MM | 1.22MM | 3/8″OD | 18G | 7.08 | 0.271 |
| 9.52MM | 0.91MM | 3/8″OD | 20G | 7.70 | 0.210 |
| 12.7MM | 1.63MM | 1/2″OD | 16G | 9.44 | 0.484 |
| 12.7MM | 1.22MM | 1/2″OD | 18G | 10.26 | 0.375 |
| 12.7MM | 0.91MM | 1/2″OD | 20G | 10.88 | 0.288 |
| 14.29MM | 0.91MM | 9/16″OD | 20G | 12.47 | 0.550 |
| 15.88MM | 1.63MM | 5/8″OD | 16G | 12.62 | 0.622 |
| 15.88MM | 1.22MM | 5/8″OD | 18G | 13.44 | 0.479 |
| 15.88MM | 0.91MM | 5/8″OD | 20G | 14.06 | 0.365 |
| 19.05MM | 3.25MM | 3/4″OD | 10G | 12.55 | 1.376 |
| 19.05MM | 1.63MM | 3/4″OD | 16G | 15.79 | 0.761 |
| 19.05MM | 1.22MM | 3/4″OD | 18G | 16.61 | 0.583 |
| 19.05MM | 0.91MM | 3/4″OD | 20G | 17.23 | 0.442 |
| 22.22MM | 1.63MM | 7/8″OD | 16G | 18.96 | 0.899 |
| 22.22MM | 1.22MM | 7/8″OD | 18G | 19.78 | 0.687 |
| 25.4MM | 1.63MM | 1″OD | 16G | 22.14 | 1.038 |
| 25.4MM | 1.22MM | 1″OD | 18G | 22.96 | 0.791 |
| 25.4MM | 0.91MM | 1″OD | 20G | 23.00 | 0.597 |
| 28.58MM | 1.63MM | 1-1/8″OD | 16G | 25.32 | 1.177 |
| 31.75MM | 1.63MM | 1-1/4″OD | 16G | 28.49 | 1.316 |
| 31.75MM | 1.22MM | 1-1/4″OD | 18G | 29.31 | 0.998 |
| 34.92MM | 1.63MM | 1-3/8″OD | 16G | 31.66 | 1.454 |
| 38.1MM | 3.25MM | 1-1/2″OD | 10G | 31.60 | 3.040 |
| 38.1MM | 1.63MM | 1-1/2″OD | 16G | 34.84 | 1.593 |
| 38.1MM | 1.22MM | 1-1/2″OD | 18G | 35.66 | 1.206 |
| 44.45MM | 3.25MM | 1-3/4″OD | 10G | 37.95 | 3.600 |
| 44.45MM | 1.22MM | 1-3/4″OD | 18G | 42.01 | 1.410 |
| 50.8MM | 3.25MM | 2″OD | 10G | 44.30 | 4.140 |
| 50.8MM | 1.63MM | 2″OD | 16G | 47.54 | 2.418 |
| 50.8MM | 1.22MM | 2″OD | 18G | 48.36 | 1.621 |
| 57.2MM | 3.25MM | 2-1/4″OD | 10G | 50.70 | 4.700 |
| 63.5MM | 3.25MM | 2-1/2″OD | 10G | 57.00 | 5.248 |
| 63.5MM | 1.63MM | 2-1/2″OD | 16G | 60.24 | 2.703 |
| 69.85MM | 3.25MM | 2-3/4″OD | 10G | 63.35 | 5.810 |
| 76.2MM | 3.25MM | 3″OD | 10G | 69.70 | 6.354 |
| 82.55MM | 3.25MM | 3-1/4″OD | 10G | 76.05 | 6.910 |
| 88.90MM | 3.25MM | 3-1/2″OD | 10G | 82.40 | 7.460 |
| 95.25MM | 3.25MM | 3-3/4″OD | 10G | 88.75 | 8.020 |
| 107.95MM | 3.25MM | 4-1/4″OD | 10G | 101.45 | 9.670 |
| 133.5MM | 3.25MM | 5″ID | 10G | 127.00 | 11.800 |
| 158.9MM | 3.25MM | 6″ID | 10G | 152.40 | 13.900 |
